Documenting a flex-rigid stack with diagonal symmetry

SPEEDSTACK

Documenting a flex-rigid stack with diagonal symmetry

Contents

00:00 Introduction
00:14 Reviewing a finished stackup print out
00:45 Reviewing the stackup in Speedstack
00:54 Start with the Bill of Materials (BOM)
01:20 Open the Navigator and copy the BOM (4 times)
01:51 Introducing a space for clarity
02:25 Deleting material above and below the flex area
04:22 Renaming stacks
04:55 Print Technical Report
05:39 Summary
05:58 Contact details
