Si8000m / Si9000e – importing measurement impedance from CITS

Si8000m / Si9000e

Si8000m / Si9000e – importing measurement impedance from CITS

Contents

00:00 Introduction
00:24 'Closing the loop' between predicted and measured results
00:45 Importing the CITS Log File into Si8000m / Si9000e field solvers
01:27 Reading the CITS Log File
02:45 Selecting the Data Log Record
03:12 Displaying and Analysing the Read-in Plotted Data
04:07 Graphing options e.g. Measured Impedance, Nominal Impedance and Tolerance (plus/minus)
04:40 Viewing the Data Log Records as a histogram
05:23 Summary
05:44 Contact details
