Fine tuning PCB stackups with Si Project

Fine tuning PCB stackups with Si Project

Contents

00:00 Introduction
00:15 Sharing impedance control structures between Speedstack and Si8000
00:50 Opening an example stackup in Speedstack
01:30 Copy structure information to Si project
02:04 Si8000 – paste from Speedstack
02:10 Calculate each structure individually in Si8000
02:40 Goal seek on line width to correct Impedance
02:58 Setting a tolerance on the line width to view spread of Impedance values
03:50 Copy structure back to Speedstack
03:59 Speedstack – Import From Field Solver
04:30 Re-calculate and review CI Results
04:55 Summary
05:06 Contact details
