Design and document flex-rigid stackups with Speedstack Flex

SPEEDSTACK

Design and document flex-rigid stackups with Speedstack Flex

Contents

00:00 Introduction
00:36 Speedstack Flex – document unlimited layers and cross sections
01:02 12 layer example
01:48 Navigator view
02:10 Technical Report of the whole stackup
03:05 Add a Sub Stack using Copy and Paste of existting stack
03:30 Add Controlled Impedance structure
03:53 Aligning the No Flow Prepreg to the Coverlay
05:27 Confirm alignment on Technical Report
06:06 Proportinal Stack View verification of dimensions
06:48 3D Stack view
07:00 Summary
07:24 Contact details
